Nedo X-Liner 5P

Easy, single-button operation

Easy, single-button operation

Easy, single-button operation

X-Liner 5P

X-Liner 5P

Self-levelling 5-beam point laser


Self-levelling 5-beam point laser which transmits three horizontal and two vertical laser points: to the front, left, right, up and down.
The laser points are arranged in an exact right angle to one another. The horizontal laser points are all at one height. Ideal for rapid horizontal levelling, vertical alignment, plumbing and for marking off right angles jobs.

The strong magnet on the universal adapter allows the X-Liner 5P to be easily attached to steel girders.
Features

Features

  • 5 highly visible laser points aligned exactly at right angles
  •  Reliable self-levelling operation
  •  Robust pendulum with magnetic damping
  •  Universal adapter with strong magnet, 1/4’’ and 5/8’’ mounting thread
Applications

Perfect for levelling, aligning and marking off right angles, especially for applications such as:


  •  Dry lining
  •  Electrical installations
  •  Carpentry
  •  Sanitary installations
  •  Alignment of construction components
Technical data

X-Liner 5P

Ref.-No. 460871
Accuracy ± 0.3 mm/m
Self-levelling range ± 4°
Working range Ø 30 m
Laser Laser class 2, 635 nm
Protection class IP 54
Power supply 2 x 1.5 V type Mignon / AA
Operation duration approx. 33 h
Connection thread 1/4’’
Scope of delivery

Scope of delivery

X-Liner 5P

Ref.-No. 460871
  • 5-beam point laser X-Liner 5P
  • Universal adapter with 1/4’’ and 5/8’’ mounting thread and magnet
  • Fixing straps
  • Target board
  • Batteries
  • Carrying case
